SK-3501 U3

akitio-sk3501-u3
akitio-sk3501-u3 akitio-sk3501-u3-front akitio-sk3501-u3-back

USB 3.0 SuperSpeed




SK-3501 U3

The SK-3501 HDD enclosure provides a combination of cutting-edge technology, durability and flexibility. Stylish, compact and simple to use, this fanless aluminum enclosure is designed for the latest 3.5" SATA hard drives and ideal for quiet working environments.

Features
  • USB 3.0 SuperSpeed connectivity
  • USB 2.0 backwards compatible
  • Durable all aluminum enclosure
  • Large heatsink for passive cooling
  • Stackable
  • Fanless

USB 3.0 SuperSpeed

By incorporating USB 3.0 SuperSpeed technology, AKiTiO's SK-3501 U3 is able to break the USB 2.0 barrier, delivering up to 10 times the speed of the older USB connection. At the same time, it is still backwards compatible with the widely used USB 2.0 technology.

SK-3501 U3 Desktop Hard Drive Enclosure

SK-3501 U3

  • SM3-U3JS-AKT1U (without drive)

  • SM3-U3JS-AKT1UH (1 x 2TB HDD)


  • CE

  • FCC

  • VCCI

  • BSMI


  • 2-year limited warranty


  • High quality aluminum for optimized heat dissipation


  • 3.5" SATA-I, SATA-II or SATA-III hard disk drive

  • Capacity 80GB - 12TB

N/A

  • 1x USB 3.0 SuperSpeed port (backwards compatible with USB 2.0)


  • USB 3.0 up to 5Gbps (625MB/s) *

  • USB 2.0 up to 480Mbps (60MB/s)


  • USB 3.0: Windows XP or above

  • USB 2.0: Windows XP or above

  • Your hardware device must have the correct corresponding port (e.g. USB 3.0, USB 2.0 or PCI card)


  • USB 3.0: Mac OS 10.7 or above

  • USB 2.0: Mac OS 10.2 or above

  • Your hardware device must have the correct corresponding port (e.g. USB 3.0, USB 2.0 or PCI card)


  • Operating Temperature: 5°C ~ 35°C

  • Storage Temperature: -20°C ~ 60°C

  • Relative Humidity: 5% ~ 95% (non-condensing)


  • External power supply (UL, cUL, PSE, CE)

  • Input: AC 100-240V, 0.5A, 50-60Hz

  • Output: DC +12V/3A

N/A

  • 8.7 inches x 4.5 inches x 1.5 inches

  • 22.2cm x 11.4cm x 3.9cm


  • SK-3501 enclosure (HDD not included)

  • USB 3.0 cable

  • Power adapter

  • User manual


  • Retail Box Size: 10.8 x 8.4 x 3.5 in. (27.5 x 21.3 x 8.8 cm)

  • Carton Size (10pcs per carton): 17.9 x 17.6 x 11.6 in.(45.5 x 44.6 x 29.4 cm)

  • Gross Weight: 1.13 kg (retail box), 12.2 kg (carton)


  • When installing 6TB drives, only two out of the four screws can be used to mount the drive.

  • The SM3-U3AS-AKTU with the 12V/2A power adapter has been replaced by the SM3-U3JS-AKT1U with a 12V/3A power adapter.
